L CHECKER IKD3061 Features
L CHECKER IKD3061 Description
The IKD 3061 is an adopter connected to IKD Ratio Testers, and measures the inductance of a tested standard coil in the transformation ratio test during the Ratio Tester is running. A conforming limit is set by adjusting the meter relay. Results of the judgement are indicated by lamp and buzzer. The IKD 3061 is further equipped with an external NG output which enables synchronization with other NG signals.
L CHECKER IKD3061 Specifications
| Power supply | AC100V,50/60Hz |
|---|---|
| Test frequency | Depends on Ratio Tester(0.5V, 1kHz or 10kHz) |
| Measurement range | 1.6mH to 10H(at 1kHz),160μH to 1H(at 10kHz) |
| Measurement circuit modes | LS,LP Both are available to all ranges |
| Dissipation factor(D) | Must be less than 5 |
| Indication and Comparator | Upper and lower limit setting with meter relay(Dissipation factor not judged) |
| Accurasy | + or -5% |
| Calibration | Adjusted with CAL volume at the front panel |
| Dimensions | 283×103×235(W×H×D) |
| Color | Light gray |
| Weight | Approx 3.5Kg |
